2003 Subaru Forester Remote 88036-AE060 88035-AC231 88036-XA010 A269ZUA111

Important:Please make sure that your smart key fob looks identical and matches any of the part numbers or FCC IDs listed below. Contact Us with your VIN if you don’t have an existing remote for comparison.

Part Numbers: 88036-AE060 and 88035-AC231

FCC ID: A269ZUA111

Buttons: Lock and Unlock

Frequency: 433 Mhz

Remote Programming:

Battery: CR2025 (included)

1. Sit in the driver’s seat and close all doors, rear gate and trunk lid.
2. Open the driver’s door.
3. Close the door.
4. Insert keys in ignition. Turn the ignition switch from LOCK to ON (as far as you can go without cranking the engine) ten times in rapid succession (within 15 seconds), ending in LOCK. The horn chirps once to indicate that the system has entered programming mode.
5. Open the driver’s door.
6. Close the driver’s door
7. Press any button on the transmitter you wish to program top the system. The horn will chirp two times to indicate that the transmitter has been programmed.
8. Any additional transmitters can also be programmed at this time (including your old ones.) Repeat steps 5 through 7 for each additional transmitter.
9. Remove the ignition key from the ignition switch. The horn will chirp three times to indicate system is out of programming mode.
